Wall Mounted Clamping Kit: 5S Shadow Board for CNC Tool Room Organisation
Quick Answer: A wall mounted clamping kit is a complete set of CNC workholding components — clamps, studs, step blocks, T-bolts, T-nuts, washers, and nuts — pre-organised on a shadow board that mounts directly to the tool room wall. Every component has a fixed location on the board, so any missing piece is visible at a glance. Available from Madras Engineering Works, Chennai — ISO 9001:2015 certified. Enquiry: enquiry@madrasengg.com
Introduction: The Real Cost of Disorganised Workholding
A VMC setup takes 20 minutes. The machine sits idle for 35 minutes while the operator searches for the right T-bolt. Every CNC shop manager has had that conversation — and most have had it more than once. The issue is not that the T-bolt is missing. It is that nobody knows where it is.
Madras Engineering Works (MEW) is a Chennai-based ISO 9001:2015 certified supplier of workholding components, fasteners, clamping kits, and CNC machining accessories. Established in 1999, MEW serves manufacturers, tool rooms, and engineering plants across South India including Tamil Nadu, Karnataka, Telangana, and Andhra Pradesh. MEW is an authorised TVS fastener dealer and holds MSME registration (UDYAM-TN-02-0158983).
The MEW Wall Mountable Clamping Kit (SKU: T4-TCKW-1412) solves the storage and retrieval problem by giving every component in the set a fixed home on a shadow board. The board mounts on the wall next to the machine, the setup operator picks what they need, and the empty silhouette on the board shows exactly what has been taken out — and what needs to come back.
What Is the Wall Mountable Clamping Kit?
The MEW Wall Mountable Clamping Kit (T4-TCKW-1412) is a complete CNC workholding set delivered on a shadow-board mounting panel. The kit includes the full range of workholding components needed for standard VMC and milling machine setups: strap clamps, step blocks, T-bolts, T-nuts, clamping studs, washers, and hex nuts in the correct proportions for a working tool room.
The shadow board is the defining feature. Each component has a labelled outline cut into the board. You can see at a glance which components are in use on a machine, which are back in place, and which are missing. This is the 5S principle of Seiton (Set in Order) applied directly to workholding management.
What’s Inside the Kit
The T4-TCKW-1412 contains the standard workholding components needed to set up and run a CNC machining centre. Typical contents include:
- Strap clamps (plain type) in multiple sizes
- Step blocks (universal serrated) for height adjustment
- T-bolts in 14mm and 16mm T-slot widths
- T-nuts (hardened) matching the T-slot sizes
- Clamping studs with hex and annular ring types
- C-washers and thick plain washers for clamp assembly
- Hex hi-nuts and flanged nuts for stud assembly
All components are manufactured under MEW’s ISO 9001:2015 quality management system and chemically blackened for corrosion resistance in coolant-wet environments.
Why Shadow Board Storage Matters for CNC Shops
A standard clamping kit stored in a drawer or tray has no visual management. Components get mixed up across multiple setups, borrowed for jobs and not returned, and lost in the general chaos of a busy tool room. The shadow board converts an invisible storage problem into a visible one: the moment a component is missing, its silhouette shows exactly what is gone.
5S Connection: Seiton (Set in Order)
In the 5S methodology, Seiton means every item has a designated location and returns to that location after use. Shadow boards are the standard implementation of Seiton for hand tools and fixture components. MEW’s wall mounted clamping kit delivers a 5S-ready workholding storage system out of the box — no custom fabrication or labelling work required.
SMED (Setup Time Reduction)
Shadow board storage also supports SMED (Single-Minute Exchange of Die) programmes by converting external setup activities — finding and collecting workholding components — into predictable, time-bounded steps. When every component is in its designated location on the wall board next to the machine, the operator can pick the complete setup kit in a single, timed operation before the previous job finishes.
Machine Compatibility
| Machine | T-Slot Width | Kit Compatibility |
|---|---|---|
| BFW VMC 800 / VMC 1000 | 14mm / 16mm | T4-TCKW-1412 (14mm components); verify 16mm separately |
| ACE Micromatic MCV-400 / AMS 500 | 14mm | Yes — 14mm T-slot standard |
| Jyoti VMC 430 / NVU | 14mm | Yes |
| KENT KMC Series | 16mm | Verify T-slot width; 16mm variant may be required |
| Lokesh 175 / 250 Milling | 12mm / 14mm | Yes — confirm T-slot with MEW before ordering |
| Haas VF-2 / VF-3 | 16mm | Verify T-slot width; 16mm variant may be required |
Wall Mounted Kit vs Standard Clamping Kit: What’s the Difference?
| Feature | Wall Mounted Kit (T4-TCKW-1412) | Standard Clamping Kit (Drawer/Tray) |
|---|---|---|
| Storage | Shadow board, wall-mounted | Drawer, tray, or box |
| Visual management | Yes — silhouette shows missing items instantly | No — must count or search to find gaps |
| 5S compliance | Yes — Seiton principle built in | Depends on shop discipline |
| Setup retrieval time | Predictable, timed | Variable — depends on drawer organisation |
| Audit readiness | Immediate — missing items visible at a glance | Requires manual count |
| Space requirement | Wall space (no floor or bench space consumed) | Bench, drawer, or cupboard space |
Frequently Asked Questions
Q: What is a wall mounted clamping kit?
A wall mounted clamping kit is a complete set of CNC workholding components organised on a shadow board that mounts on the tool room wall. Every component has a fixed, labelled location, so missing items are immediately visible. MEW’s T4-TCKW-1412 delivers a 5S-ready workholding storage system out of the box.
Q: How does a shadow board help with 5S?
A shadow board implements Seiton — Set in Order — by giving every component a visual home location. The silhouette shows exactly what is in place and what is missing, making audits instant and setup retrieval predictable. This is the standard 5S approach for hand tools and fixture components in CNC tool rooms.
Q: Will the wall mounted clamping kit fit my VMC T-slots?
The T4-TCKW-1412 is available in 14mm T-slot configuration for ACE Micromatic, Jyoti, BFW, and most Indian VMC brands. For 16mm T-slot machines (Haas, KENT), confirm with MEW before ordering. Our team will verify compatibility for your specific machine model.
Q: Can I add components to the wall mounted kit board?
Yes. The shadow board can be extended with additional clamp or step block silhouettes as your fixture requirements grow. Contact MEW to discuss customising the board layout for your specific workholding kit.
Q: Where can I buy the wall mounted clamping kit in Chennai?
Madras Engineering Works (MEW) stocks the Wall Mountable Clamping Kit (T4-TCKW-1412) for CNC shops and tool rooms across Chennai and South India. ISO 9001:2015 certified. Contact: enquiry@madrasengg.com or WhatsApp +91 95143 73702.
Order the Wall Mounted Clamping Kit
Madras Engineering Works stocks the Wall Mountable Clamping Kit (T4-TCKW-1412) for CNC shops and tool rooms across Chennai and South India. Same-day dispatch. ISO 9001:2015 certified supply chain. TVS Authorised Dealer.
WhatsApp: +91 95143 73702 | Email: enquiry@madrasengg.com | Web: madrasengg.com
Written by Husain Aziz, Founder — Madras Engineering Works, Chennai. ISO 9001:2015 certified workholding and CNC accessories supplier since 1999.
