Quick Answer: A flat strap clamp is a low-profile hardened steel clamp used to hold a workpiece onto a CNC milling table or fixture plate where vertical clearance is limited. MEW's MG-FSC series covers M8 to M36 (9x60mm to 39x400mm), applying the same clamping principle as a standard strap clamp in a thinner body so it clears the spindle, tool holder, or adjacent fixtures in multi-fixture pallet setups. Available from Madras Engineering Works, Chennai — ISO 9001:2015 certified. Enquiry: enquiry@madrasengg.com
A strap clamp that's too thick for the job doesn't fail quietly. It fouls the tool holder mid-cut, or it blocks the fixture sitting next to it on a pallet, and the job stops while someone re-specs the clamp under time pressure. This is a clearance problem, not a clamping-force problem — and the flat strap clamp exists to solve exactly this.
Madras Engineering Works (MEW) is a Chennai-based ISO 9001:2015 certified supplier of workholding components, fasteners, clamping kits, and CNC machining accessories. Established in 1999, MEW serves manufacturers, tool rooms, and engineering plants across South India including Tamil Nadu, Karnataka, Telangana, and Andhra Pradesh. MEW is an authorised TVS fastener dealer and holds MSME registration (UDYAM-TN-02-0158983).
Here is everything you need to know.
What Is a Flat Strap Clamp?
A flat strap clamp is a hardened steel clamping element that presses a workpiece down onto a machine table or fixture plate — the same mechanical function as a standard strap clamp, but built with a reduced body height. The low profile means it takes up less vertical space above the workpiece, which matters directly in any setup where something else — a spindle, a tool holder, an adjacent fixture — shares that space.
MEW's MG-FSC series is machined from medium carbon steel, hardened and tempered to 24–32 HRC, and chemically blackened for corrosion resistance. It's tightened with a T-bolt or clamping stud through its slot, the same way any strap clamp is installed, and pivots on a step block or support to set the clamping angle against the workpiece surface.
Where Is It Used?
- CNC machining centres running multi-fixture pallet setups
- Jig and fixture construction with restricted vertical clearance
- Tool rooms fitting clamps around obstructions or adjacent tooling
- Pallet-changer setups where clamp height is constrained by machine geometry, not workpiece geometry
Sizes Available — MG-FSC Series
| Part No | D x L (mm) | Screw Size | Weight (kg) |
|---|---|---|---|
| MG-FSC-960 | 9 x 60 | M8 | 0.15 |
| MG-FSC-1180 | 11 x 80 | M10 | 0.25 |
| MG-FSC-14100 | 14 x 100 | M12 | 0.5 |
| MG-FSC-14125 | 14 x 125 | M12 | 0.65 |
| MG-FSC-18125 | 18 x 125 | M16 | 1.0 |
| MG-FSC-18160 | 18 x 160 | M16 | 1.25 |
| MG-FSC-22160 | 22 x 160 | M20 | 2.1 |
| MG-FSC-22200 | 22 x 200 | M20 | 2.65 |
| MG-FSC-26200 | 26 x 200 | M24 | 3.25 |
| MG-FSC-26250 | 26 x 250 | M24 | 4.15 |
| MG-FSC-33250 | 33 x 250 | M30 | 4.8 |
| MG-FSC-33315 | 33 x 315 | M30 | 7.9 |
| MG-FSC-39315 | 39 x 315 | M36 | 8.35 |
| MG-FSC-39350 | 39 x 350 | M36 | 11.4 |
| MG-FSC-39400 | 39 x 400 | M36 | 13.2 |
Match the screw size (M8–M36) to your existing T-bolt or clamping stud. Not sure which size your setup needs? WhatsApp your T-slot and stud size and we'll confirm.
Best Suited For
| Machine | T-slot Width | Stud Thread | Notes |
|---|---|---|---|
| BFW BMV 45+ / 50 | 14mm | M12 | MG-FSC-14100 / 14125 |
| ACE Micromatic MCV-400 / 450 | 14mm | M12 | MG-FSC-14100 / 14125 |
| Jyoti VMC 850 / NVU | 14mm | M12 | MG-FSC-14100 / 14125 |
| Haas VF-2 / VF-3 | 16mm | M16 | MG-FSC-18125 / 18160 — confirm slot |
| FANUC ROBODRILL | 14mm | M12 | MG-FSC-14100 / 14125 |
The Problem It Solves
On a multi-fixture pallet, every millimetre of vertical space is budgeted. A standard-height strap clamp that works fine on a single-part setup can foul the tool holder or an adjacent fixture the moment you add a second or third part to the same pallet. The result is either a stopped job while someone finds a lower clamp, or — worse — a clamp left in place that clips the spindle on a rapid move.
A flat strap clamp removes this failure mode at the design stage. Same holding principle, no interference, no mid-job redesign.
Technical Specifications
- Material: Medium Carbon steel, hardened and tempered to 24-32 HRC, Chemically Blackened
- Series: MEW-Grip MG-FSC
- Size range: M8 to M36 (9x60mm to 39x400mm), 15 sizes
- Weight range: 0.15kg (MG-FSC-960) to 13.2kg (MG-FSC-39400)
- Note: When pairing with spherical washers, use MEW Hold Series MH-SWCS
As of 2026, the full MG-FSC range is in stock for Chennai dispatch.
Flat Strap Clamp vs Zero-Point Clamping — Does Zero-Point Replace This?
Mostly, for standard parts — but not always, and knowing the difference saves you from either an unnecessary purchase or a fixture design that doesn't work.
A zero-point clamping system is a quick-change interface between the machine table and whatever sits above it. Precision locating studs lock a fixture into the same position every time, in seconds, instead of indicating and bolting a plate down by hand.
For a standard rectangular or block part, the typical zero-point setup pairs the base with a self-centering vise, mounted directly on it. The vise jaws do the clamping — no strap clamp, no T-slot-bolted plate involved. If your part fits in a vise, moving to zero-point genuinely does replace strap-clamp-on-plate fixturing for that job.
Where a flat strap clamp stays the right tool, even on a zero-point line: parts that don't fit a vise. That includes irregular or oversized geometry, multiple different parts loaded on one pallet in a single setup, and thin-wall or delicate parts where vise jaw pressure would distort the material rather than hold it. For any of these, the shop runs a custom sub-plate on the zero-point base instead of a vise — and that plate still uses clamps, flat strap clamps included, especially where low clearance rules out a standard-height clamp.
The decision isn't "zero-point or clamps" — it's whether your part fits in a vise. If it does, zero-point plus a vise likely replaces this clamp for that job. If it doesn't, you're still speccing one.
FAQ
Q: What sizes does the flat strap clamp come in?
A: MEW's MG-FSC series covers M8 to M36 across 15 sizes, from 9x60mm (0.15kg) to 39x400mm (13.2kg). Match the size to your existing T-bolt or clamping stud thread. Available from Madras Engineering Works, Chennai — enquiry@madrasengg.com
Q: What's the difference between a flat strap clamp and a standard strap clamp?
A: Both apply the same downward clamping force. The flat strap clamp has a reduced body height, built for setups where vertical clearance — not clamping force — is the constraint. Available from Madras Engineering Works, Chennai — enquiry@madrasengg.com
Q: Will zero-point clamping replace clamps like this?
A: For a standard block part, mostly yes — the typical zero-point setup uses a self-centering vise, and the vise jaws do the clamping instead of a strap clamp on a plate. It stays relevant for irregular or oversized parts, multi-part pallets, and thin-wall parts where vise pressure would distort the material — those still use a custom sub-plate with clamps. Available from Madras Engineering Works, Chennai — enquiry@madrasengg.com
Q: What T-slot size does the flat strap clamp fit?
A: It's sized to match your existing T-bolt or stud thread rather than the slot directly — most Indian-made VMCs under 1000mm table size use a 14mm slot with M12 studs (MG-FSC-14100/14125); Haas VF-series machines use 16mm/M16 (MG-FSC-18125/18160). Confirm your exact slot and stud size before ordering. Available from Madras Engineering Works, Chennai — enquiry@madrasengg.com
Q: Where can I buy a flat strap clamp in Chennai?
A: Madras Engineering Works (MEW) stocks the full MG-FSC range for same-day dispatch from Chennai. ISO 9001:2015 certified supply chain. Contact: enquiry@madrasengg.com
Q: Why does my strap clamp keep fouling the tool holder?
A: Standard-height strap clamps are sized for single-part setups. On a multi-fixture pallet, the added vertical stack from a second or third part can put the clamp body in the tool's flight path. A flat strap clamp's reduced height is designed specifically to avoid this. Available from Madras Engineering Works, Chennai — enquiry@madrasengg.com
Get the Right Size Clamp for Your Setup
Whether it's a single flat strap clamp or a full fixture spec, Madras Engineering Works stocks the full MG-FSC range for all standard VMC and milling machine T-slot sizes.
Same-day dispatch from Chennai.
ISO 9001:2015 certified supply chain.
Email: enquiry@madrasengg.com
Web: madrasengg.com
Location: Chennai, Tamil Nadu
Not sure which size fits your clearance? WhatsApp your T-slot and stud size and we'll confirm before you order.
Written by Husain, Founder of Madras Engineering Works — an ISO 9001:2015 certified industrial supplier in Chennai specialising in workholding, clamping and CNC accessories. Need help speccing the right part? WhatsApp +91 95143 73702 or email enquiry@madrasengg.com.
